2024 FDX Tandem Axle Steel Gooseneck Trailer 20,000lb.

24953
Apply here!

Gooseneck Flat Bed Trailers
Low Pro Trailers

102 x 30'
GVWR: 20000#

This will notify your salesperson, are you ready?

Photos

Upload Photos, Jpg or Png only.

Title:

Description:

Privacy Status:

% done (/ bytes)

Uploaded video with id . Polling for status...

By uploading a video, you certify that you own all rights to the content or that you are authorized by the owner to make the content publicly available on YouTube, and that it otherwise complies with the YouTube Terms of Service located at http://www.youtube.com/t/terms

Standard Features

10,000 lbs (per axle)
2-5/16" Adjustable Coupler
3/8" Gr70 Safety Chains
2 - 12,000 LB Dropleg Jacks
2 - 10,000 lb. Electric Brake Spring Axles
Slipper Spring Suspension
235/80R16 10 Ply. Dual Tires
16" Dual Black Mod Rims
12" x 19 lbs. I-Beam Main Frame
12" x 19 lbs. I-Beam Neck (96" Long)
3" Channel 16" O.C. Crossmembers
2" x 5" x 1/8" Tubing Outer Deck Frame
Front Toolbox Between Risers
2" Treated Lumber Deck
(4) D-Rings (welded outside corners)
3-5/8" x 1-1/2" Stake Pockets
3/16" Thread Plate Fenders
Straight Deck w/8' Slide-In Channel Ramps
2" Rub Rail with Spools & Stake Pockets
Side Step
Electric Breakaway Kit
DOT Reflective Tape
7-Way Plug
All Weather Wiring Harness
LED Lighting
Prep: Grit Blast
Powder Coat Finish
5 Year Axle Warranty - 3 Year Structural Warranty - 1 Year Paint Warranty

Dry Weight: 7628lb
Payload: 12,372lb

Option Photos

Jet Black

Model Description

Model #: FDX30GN20K
Dimensions: 102 x 30'
GVWR: 20000# lbs
Axles: TANDEM
Brakes: ELECTRIC
Deck Height: 35"
Wheels: 8

Colors
- Jet Black

Dove Tails
- 5' Self-Clean Dovetail w/ Maxx Ramps

Frame Bridge
- Under Frame Bridge (Standard on 30' +)
- Pipe Bridge (Standard on 30' +)
