10,000 lbs (per axle)
2 5/16" Adjustable Coupler Round (25,000 lb)
12" I-Beam (19 lbs/ft) Neck
26,400 Lb 3/8 x 36 G#70 Safety Chains
2-10K Drop Leg Spring Return Jack
2-10,000 Lb Dexter Spring Elec Brakes
235/80 R16 LRE (w/ spare) Tires
HDSS Suspension
16" 8-Hole Dual Wheels
12" Pierced I-Beam (19 lbs/ft) Frame
3" Channel 16" OC (3.5 lbs/ft) Crossmembers
Front Tool box
Winch Plate
Fold-Down Spare Tire Mount
Treated Wood Floor
8' Slide-In Ramps
LED D.O.T. Stop, Tail, Turn and Clearance Lighting
16 Ga. 5-Way Double Insulated Harness w/Cold Weather Cold 7-way plug
Sherwin-Williams Powdura OneCure, Primer w/Polyester TGIC Gloss Powder Top Coat
Mechanical and/or Chemical Pretreatment for Maximum Paint Adhesion
Black

Model #: GP0230102
Dimensions: 102 x 30'
GVWR: 22000# lbs
Axles: TANDEM
Brakes: ELECTRIC
Payload: 14108#
Weight: 7892#
Wheels: 9

Colors
- Black

Dove Tails
- 5' Self Clean Dove w/Max Ramps (Not Available with Drop Axles)

Side Steps
- 2-MAX-STEPS (15")

Tire Upgrades
- ST235/80 R16 LRE 10 Ply. (Black Wheels)
