7,000 Lb (ea axle)
2-5/16" Adjustable Coupler
18,800 Lb 5/16 x 28 G#70 Safety Chains
1-10K Drop Leg Spring Return Jack
2-7,000 Lb Cambered Dexter Torsion UP 2 Elec Nev-R-Adjust Brakes
235/80 R16 Radial Tires
16" 8-Hole Wheels
Torsion Axle Suspension
8" I-Beam (13 lbs/ft) Neck
8" I-Beam (13 lbs/ft) Frame
Front Rail w/2" x 2" x 3/16" Angle Iron Uprights
3" Channel 16" OC (3.5 lbs/ft) Crossmembers
Treated Wood Floor
Weld On Diamond Plate Fenders
2" x 2" x 1/8" Tubing Top Rail
LED D.O.T. Stop, Tail, Turn and Clearance Lighting
16 Ga. 5-Way Double Insulated Harness w/Cold Weather Cold 7-way plug
3" x 10 w/1.25" Shaft
(4) 3" Standard D-Rings
Sherwin-Williams Powdura OneCure, Primer w/Polyester TGIC Gloss Powder Top Coat
Mechanical and/or Chemical Pretreatment for Maximum Paint Adhesion
Black

Model #: TH8324072
Dimensions: 83 x 24'
GVWR: 14000# lbs
Axles: TANDEM
Brakes: ELECTRIC
Payload: 9700#
Weight: 4300#
Wheels: 4

Colors
- Black

D-Rings
- 2 x D-Rings 3" Weld On

Floors
- Treated Wood Floor

Rub Rail
- 2" Rub Rail

Tire Upgrades
- ST235/80 R16 LRE 10 Ply. (BLACK WHEELS)

Toolbox
- Tool Tray
