Ord: 55827
Ser: 5WMBE1728P1006836
Status: New
White, Barn w/Ramps, 6 EH, Contractor Package
View as Catalogue

In Stock Inventory

2023 8 Wide Aluminum Flat Top V-Nose Trailer

22190
Apply here!

Aluminum Enclosed 8.5 Wide Trailers
Aluminum Frame Commercial Trailers

8' x 17'
GVWR: 9990LB


Loading


The Legend FTV series trailer combines the perimeter structure, all square
tube system and an "A LA CARTE" of available options. Still featuring the
one piece aluminum roof and bonded smooth exterior. Torsion axles and
Legend's big 3" x 6" tongue insure the long lasting use for this unit.
Legend includes their V-Nose in the length (For Example: 8 x 17 = 14' box + 3' V-Nose)

REDUCED PRICE!! REGULAR $25,995 NOW ONLY $22190!!


Standard Features

Aluminum 2" X 4" Tube Perimeter Frame
Aluminum 1" X 1.5" Radius Tube Roof Bows 16" On Center
Aluminum 2" X 3" Tube Floor Cross Members 16" On Centre
Aluminum 1" X 1.5" Tube Walls Cross Members 16" On Center
3" X 6" Extruded Aluminum Triple Tube Tongue (32")
3500LB Dexter Torsion Axles W/ E-Z Lube System
.030 Screwless Aluminum Exterior Skin
Seamless One Piece Aluminum Roof
Aluminum Wheels W/ 15" Radial Tires
ATP Fenders
Stainless Steel Door Hardware
30" X 68" Curbside Rv Side Door W/ Flush Lock & Aluminum Holdback With Black Frame
3' V-Nose
24" ATP Stone Guard
Led Exterior Lighting
(2) Led Interior Dome Lights W/ Wall Switch
3/4" Engineered Wood Flooring
3/8" Engineered Wood Interior Wall Covering
(2) Plastic Side Vents
2 5/16" Coupler
(4) 1000LB D-Rings Shipped Loose
Self Mating Rear Ramp Door W/ Spring Assist W/Stainless Steel Door Hardware
Lighted Side Entry Door Grab Handle
2000LB Top-Wind Set Back Jack W/Foot
Limited 10 Year Axle - Limited Lifetime Structural - Limited 1 Year Floor - Limited 25 Year Roof Warranty

Option Photos

White
White
Self Mating Double Rear Doors w/Ramps & Stainless Steel Hasps ILO Ramp Door
Self Mating Double Rear Doors w/Ramps & Stainless Steel Hasps ILO Ramp Door
3/4" Engineered Wood Flooring
3/4" Engineered Wood Flooring
(2) Plastic Forced Air Side Vents
(2) Plastic Forced Air Side Vents

Model Description

Model #: 817FTVTA35
Dimensions: 8' x 17'
GVWR: 9990LB lbs
Axles: TANDEM
Box Length: 14'
Brakes: ELECTRIC
Interior Height: 7'
Interior Length: 16' 9"
Interior Width: 93"
Oa Height: 8' 8"
Oa Length: 20' 2"
Oa Width: 102"
Payload: 7980LB
Rrdo Height: 6' 7"
Rrdo Width: 85"
V-Nose Length: 3'
Weight: 2010LB
Wheels: 4

110v Electrical Package
- 110V Bronze Package- (1) Exterior Power Inlet, (1) Interior Outlet, (1) 48" Led Interior Light W/ (1) Wall Switch (Inlet & Outlet Must Be Back To Back)

12v Lighting
- (2) 12V Rectangle Led Interior Dome Lights W/ Wall Switch
- 2 x Add 8" LED Dome Light

Axles
- Tandem Axle 5200LB Torsion Axle ILO (2) 3500LB Torsion Axles: ST235/80R16 (8 Hole) (8500LB Gvwr) (Requires Upgrade to 6" Frame)

Ceilings
- White Vinyl Ceiling (Per Floor Foot)

Color
- White

Couplers
- Adjustable 2 5/16" Coupler

Doors
- Self Mating Double Rear Doors w/Ramps & Stainless Steel Hasps ILO Ramp Door

Frame
- 6" Aluminum Tube Frame ILO Of 4" Frame
- Fixed Aluminum Ladder

Interior Height
- 6" Additional Height(Per Foot of Floor)

Interior Walls
- 3/8" Wood W/ White Vinyl Walls Screwed ILO 3/8" Eingineered Wood (Per Foot Fl)

Jacks
- 2000Lb Top-Wind Set Back Jack W/Foot
- 7,000# Drop-Leg Jack ILO Std 2,000#

Other Frame
- 14' Box (5 Ladder Racks and Catwalk)

Side Doors
- Slide-Out Step
- Upgrade Door Frame Color On Standard Rv Side Door (Silver ILO Black)
- 36" X 74" ILO 30" X 68" RV Side Door w/ Flush Lock MUST HAVE HEIGHT TO ACCOMMODATE (n/a on 5' Wides)

Vents
- Salem 2-Way Aluminum Side Vents ILO Plastic Forced Air Side Vents (Pair)

Custom Options
