3,500 Lb (ea axle)
2" A-Frame 7,000 Lb Coupler
7,600 Lb 5/16 x 29 G#30 Safety Chains
5,000 Lb Top Wind Swivel Jack
2-3,500 Lb Cambered Dexter Spring 1 Elec. Brake Forward Adjusting
205/75 R15 LRC Tires
15" 5-Hole Wheels
Multi-Leaf Spring Suspension
4" Channel (4.5 lbs/ft) Tongue
4" Channel (4.5 lbs/ft) Frame
Removable Side Rails w 2" x 2" x 1/8" SQ. Tubing Top Rail
2" x 2" x 1/8" Tubing Uprights
2" x 2" x 3/16 Angle Iron (2.44 lbs/ft) Crossmembers
Treated Wood Floor
Removable Smooth Plate Fenders
LED D.O.T. Stop, Tail, Turn and Clearance Lighting
16 Ga. 5-Way Double Insulated Harness w/Cold Weather Cold 7-way plug
Sherwin-Williams Powdura OneCure, Primer w/Polyester TGIC Gloss Powder Top Coat
Mechanical and/or Chemical Pretreatment for Maximum Paint Adhesion
Black

Model #: UT8316032
Dimensions: 83 x 16'
GVWR: 7000# lbs
Axles: TANDEM
Brakes: ELECTRIC
Payload: 5177#
Weight: 1823#
Wheels: 4

Axles
- 2 - 3,500 Lb Dexter Axles (2 Elec Brakes) Forward Adjusting

Colors
- Black

Couplers
- Coupler 2" Adjustable (4 Hole)

Fenders
- Diamond Plate Aluminum Fenders (removable)

Rear Gates
- 4' Fold In Gate Tubing w/Exp. Metal

Spring Assist
- Spring Assist on Fold Gates

Tire Upgrades
- ST205/75 R15 LRC 6 Ply. (BLACK WHEELS)
